Communication interface:
NFC for configuration
USB for configuration
Input:
50 mA Current transformer
PT100
PT500
PT1000
PTC1K
Ni100
NTC10K
Thermocouple (K, S, J, T, N, R, B, E)
4…20 mA (Ri≤5ohm) AI1
0…1 / 5 / 10 V (Ri≥110Kohm) AI1
PNP DI1
PNP DI2
0…60 mV
1…150 Kohm
Operating temperature:
0..45°C
Output:
0…10 V
4…20 mA
SSR (12/24V, 25mA output for command or alarm)
Q2 (2A resistive load 230VAC)
Q1 (2A resistive load 230VAC)
PNP DO1
PNP DO2
Power supply:
24..230V AC/DC
