Communication interface:
RS-485
NFC for configuration
USB for configuration
Input:
PNP DI2
0…1 / 5 / 10 V Ri≥110Kohm AI1
PT1000
PT100
PT500
4…20 mA Ri≤5ohm AI1
0…1 / 5 / 10 V (Ri≥110Kohm AI2)
0…60 mV
1…150 Kohm
50 mA Current transformer
PTC1K
Ni100
NTC10K
Thermocouple (K, S, J, T, N, R, B, E)
PNP DI1
PNP DI3
PNP DI4
4…20 mA Ri≤5ohm AI2
Operating temperature:
0..45°C
Output:
4…20 mA AO1
4…20 mA AO2
0…10 V AO1
0…10 V AO2
Q1 (2A resistive load 230VAC)
Q2 (2A resistive load 230VAC)
Q3 (2A resistive load 230VAC)
PNP DO1
PNP DO2
SSR (12/24V, 25mA output for command or alarm)
Power supply:
115..230V AC
Programming mode:
NFC / RFID
