VIDEO: Reading Seneca network analyzer data in Modbus network
February 9, 2022
Electricity metering and network analysis opens the new horizons for the choice of power system optimization paths.
Data on energy consumption, current and voltage in phases, active and reactive power, frequency and many other parameters can be easily obtained from the Seneca device via the Modbus network.
The data can then be conveniently displayed, stored and analyzed via the HMI panel. Control current energy consumption or production, and stay up-to-date on processes in your electrical system with Seneca S504C and S604C energy meters and network analyzers.
In this video you will see:
- CT and wiring configuration for S504 and S604 devices.
- Connection of S604C network analyzer in Modbus network with HMI.
- Reading registers from a Seneca analyzer.
- Data sampling and trend display in HMI.
If you need a electricity metering and network analysis system, contact ZTF Lāsma specialists who will help you find the most suitable and cost-effective solution. We are here to support!
